Key Highlights
- Edge Computing
- High Performance
- High Accuracy
- Dark Environment
- Energy Saving
- Solution Ready
- Easy to Install
- Easy Integration
- SDK Available
Technical Specification
| Operating Range | 0.5m to 10m, auto switch mode |
|---|---|
| Frame Rate | 5fps / 15fps / 25fps, 3 modes |
| Point of Distance per Frame | 38,528 dt |
| FoV (H x V x D) | 63.1° x 50.5° |
| Depth Accuracy | ≤ 1% of distance |
| Emitter Type | VCSEL, modulation frequency up to 80MHz |
| Wavelength | 940 nm |
| 3D Image Processor | ARM® Cortex®-M7 core (built-in) |
| I/O Port | USB Type-C |
| Power Consumption | < 1.5W avg. |
| Power Supply | 5V / 1A USB power |
| Dimension | 73mm x 28mm x 9.8mm |
| Operating Temperature | -20℃ ~ 45℃ |
| Storage Temperature | -30℃ ~ 85℃ |
